119 Altos R520 Installation Configuration Guide
4. To start RAID Web Console 2, click on start button, select System -> More
Programs -> RAID Web Console 2 Startup UI
SUSE Linux Enterprise Server 10 EM64T Installation (with
integrated SAS SW RAID)
Below information describes how to manually install SUSE Linux Enterprise
Server 10 EM64T on Altos R520 with integrated SAS SW RAID.
Drivers Required
For SUSE Linux Enterprise Server 10 EM64T Installation, the following device
drivers are required.
Device Version EasyBUILD Version
Integrated SAS SW
RAID
06.28.1110.20
06
EasyBUILD 7.1 build 600 (or later)
Onboard Chipset N/A OS built-in
Onboard Gigabit
Ethernet
7.3.15-NAPI EasyBUILD 7.1 build 600 (or later)
Onboard VGA N/A OS built-in
IOAT 2.15 EasyBUILD 8.0 build 200 (or later)
Onboard USB 2.0 N/A OS built-in
Software Required
The management utility of integrated SAS SW RAID can be found in the
EasyBUILD 7.1 build 600 (or later).
Software Version EasyBUILD Version
RAID Web Console
2
1.19-00 EasyBUILD 7.1 build 600 (or later)
Configuring integrated SAS SW RAID
Please refer to the Appendix B. for the integrated SAS SW RAID configuration.
Installation Tips
NOTE. The driver of Integrated SAS SW RAID is required for the SUSE Linux
Enterprise Server 10 EM64T installation. Please install an external USB floppy
drive for applying driver during the OS installation.
1. Since SUSE Linux Enterprise Server 10 EM64T cannot recognize the
integrated SAS SW RAID, you need to make a driver diskette from the
EasyBUILD 7.1 build 600 first before the installation.
2. Boot the system with SUSE Linux Enterprise Server 10 EM64T CD #1.
3. When you see the boot menu on the screen, select Installation and type
“brokenmodules=ahci” string in the below text tab. Then press F5 and
select YES for the driver loading in the installation. Press Enter to
To Next Page
