Acer Aspire V3-471 User Manual

Machine Maintenance Procedures 3-11
WLAN (Wireless Local Area Network) Module Removal 0
Prerequisite:
Base Door Removal
1. Find WLAN module (B) on the base assembly. Refer to Figure 3-6.
Figure 3-6. Component Location
2. Disconnect WLAN antennas (C) connected to WLAN card (Figure 3-7).
3. Remove one (1) screw (A) securing the WLAN module in place (Figure 3-7).
Figure 3-7. WLAN Module
A
B
C
A
C

Acer Aspire V3-471 Specifications

General

Optical Drive	DVD-Super Multi DL drive
Processor	Intel Core i3/i5/i7 (depending on model)
RAM	4GB DDR3
Storage	500GB HDD
Display	14-inch HD (1366x768)
Graphics	Intel HD Graphics 3000
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Weight	2.1 kg
Dimensions	342 x 245 x 25.4 mm
Ports	HDMI, VGA, Ethernet, headphone/microphone combo jack
Wireless	802.11b/g/n
