Acer Aspire V3-471 User Manual

Machine Maintenance Procedures 3-43
Camera Module Installation 0
1. Place Camera Module on the LCD module. Refer to Figure 3-41.
2. Connect the camera cable (B) to connector (C). Refer to Figure 3-42.
3. Install LCD Bezel.

Acer Aspire V3-471 Specifications

General

Optical Drive	DVD-Super Multi DL drive
Processor	Intel Core i3/i5/i7 (depending on model)
RAM	4GB DDR3
Storage	500GB HDD
Display	14-inch HD (1366x768)
Graphics	Intel HD Graphics 3000
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Weight	2.1 kg
Dimensions	342 x 245 x 25.4 mm
Ports	HDMI, VGA, Ethernet, headphone/microphone combo jack
Wireless	802.11b/g/n
