1-54 Hardware Specifications and Configurations
System I/O Address Map (Continued)
I/O address (hex) System Function (shipping configuration)
00B0 - 00B1 Programmable interrupt controller
00B2 - 00B3 Motherboard resources
00B4 - 00B5 Programmable interrupt controller
00B8 - 00B9 Programmable interrupt controller
00BC - 00BD Programmable interrupt controller
00C0 - 00DF Direct memory access controller
00F0 - 00F0 Numeric data processor
03B0 - 03BB Intel(R) HD Graphics Family
03C0 - 03DF Intel(R) HD Graphics Family
0400 - 0453 Motherboard resources
0454 - 0457 Motherboard resources
0458 - 047F Motherboard resources
04D0 - 04D1 Programmable interrupt controller
0500 - 057F Motherboard resources
0680 - 069F Motherboard resources
0D00 - FFFF PCI bus
1000 - 100F Motherboard resources
164E -164F Motherboard resources
2000 - 20FF Realtek PCIe GBE Family Controller
2000 - 2FFF Intel(R) 7 Series/C216 Series Chipset Family PCI Express Root Port 3 - 1E14
3000 - 307F NVIDIA GeForce GT 620M
3000 - 3FFF Xeon E3-1200/2nd Generation Intel(R) Core(TM) Processor Family PCI
Express Root Port - 0101
4000 - 403F Intel(R) HD Graphics Family
4040 - 405F Intel(R) 7 Series/C216 Series Chipset Family SMBus Host Controller - 1E22
4060 - 407F Intel(R) 7 Series Chipset Family SATA AHCI Controller
4080 - 4087 Intel(R) 7 Series Chipset Family SATA AHCI Controller
4088 - 408F Intel(R) 7 Series Chipset Family SATA AHCI Controller
4049 - 4093 Intel(R) 7 Series Chipset Family SATA AHCI Controller
4094 - 4097 Intel(R) 7 Series Chipset Family SATA AHCI Controller
FFFF - FFFF Motherboard resources
FFFF - FFFF Motherboard resources
