Acer Aspire V3-471 User Manual

3-44 Machine Maintenance Procedures
LCD Panel Removal 0
Prerequisite:
LCD Bezel Removal
1. Remove the microphone (B) from its compartment on the LCD cover (Figure 3-43).
2. Remove the six (6) screws (A) from the LCD panel (Figure 3-43).
Figure 3-43. LCD Panel
3. Lift the LCD panel (C) from LCD cover (Figure 3-43).
CAUTION:
!
Make sure all cables are moved away from the device to avoid damage
during LCD Panel removal.
B
A
A
A
A
C

Acer Aspire V3-471 Specifications

General

Optical Drive	DVD-Super Multi DL drive
Processor	Intel Core i3/i5/i7 (depending on model)
RAM	4GB DDR3
Storage	500GB HDD
Display	14-inch HD (1366x768)
Graphics	Intel HD Graphics 3000
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Weight	2.1 kg
Dimensions	342 x 245 x 25.4 mm
Ports	HDMI, VGA, Ethernet, headphone/microphone combo jack
Wireless	802.11b/g/n
