Acer Aspire V3-471 User Manual

3-46 Machine Maintenance Procedures
LCD Bracket Removal 0
Prerequisite:
LCD Panel Removal
1. Remove the four (4) screws (A) (Figure 3-44).
Figure 3-44. LCD Bracket
2. Remove LCD bracket from the LCD panel.
LCD Bracket Installation 0
1. Place LCD bracket on the LCD panel (Figure 3-44).
2. Install and secure four (4) screws (A) to the LCD bracket (Figure 3-44).
3. Install LCD panel.
ID Size Quantity Screw Type
A M2*3 4
A
A
A
A

Acer Aspire V3-471 Specifications

General

Optical Drive	DVD-Super Multi DL drive
Processor	Intel Core i3/i5/i7 (depending on model)
RAM	4GB DDR3
Storage	500GB HDD
Display	14-inch HD (1366x768)
Graphics	Intel HD Graphics 3000
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Weight	2.1 kg
Dimensions	342 x 245 x 25.4 mm
Ports	HDMI, VGA, Ethernet, headphone/microphone combo jack
Wireless	802.11b/g/n
