Acer Aspire V3-471 User Manual

3-36 Machine Maintenance Procedures
CAUTION:
!
Make sure all cables are moved away from the device to avoid damage
during removal.
LCD Module Installation 0
1. Place the LCD Module on the base assembly. Refer to Figure 3-34.
2. Align LCD hinges with the hinge guides on the Base Assembly. Refer to Figure 3-34.
3. Install and secure three (3) screws (A) to LCD hinges. Refer to Figure 3-33.
4. Place the cables (B) to the cable guides and secure it with the tape (C). Refer to
Figure 3-33.
5. Install Mainboard.
ID Size Quantity Screw Type
AM2.5*6 3

Acer Aspire V3-471 Specifications

General

Optical Drive	DVD-Super Multi DL drive
Processor	Intel Core i3/i5/i7 (depending on model)
RAM	4GB DDR3
Storage	500GB HDD
Display	14-inch HD (1366x768)
Graphics	Intel HD Graphics 3000
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Weight	2.1 kg
Dimensions	342 x 245 x 25.4 mm
Ports	HDMI, VGA, Ethernet, headphone/microphone combo jack
Wireless	802.11b/g/n
