Acer Aspire V3-471 User Manual

Hardware Specifications and Configurations 1-25
System Block Diagram 0
Figure 1-11. System Block Diagram
SYSTEM BLOCK DIAGRAM
Azalia
P31
EC
NPCE885L
EM-6781-T3
HALL SENSOR
P32
P31
ALC271X-VB6
AUDIO CODEC
P26
P22
HP
P27
Int. MIC
MIC JACK
P27
Touch Pad Board Con.
K/B Con.
RTL8411
10/100/1G
P28
PCIE-3
RJ45
P28
MINI CARD
WLAN
USB-10
PCIE-8
P25
CLK
SATA 1
P25
SATA - ODD
USB3-2/USB2-1
USB2-4
Bluetooth Con.
SATA - HDD
P25
Display
GFX
IMC
rPGA 989
P3, 4, 5, 6
FDI
PCI-E x1
PCH
Panther Point
SATA
DMI
P7, 8, 9, 10, 11, 12
FDI
P8
SPI ROM
DMI(x4)
DMI
IHDA
LPC
Dual Channel DDR III
DDRIII-SODIMM1
DDRIII-SODIMM2
1066/1333/1600 MHZ
P13, 14
SPI
IVY Bridge
P31
SATA 0
(PWM Type)
P31
Fan Driver
HDMI Con.
INT_CRT
INT_HDMI
P23
BATTERY
P8
RTC
X'TAL 32.768KHz X'TAL 25MHz
Speaker
P27
eDP Con.
P22
eDP
CRT Con.
P22
N13P-GS N13P-GL
N13M-GS
P15~P19
PEG TX/RX
VRAM
P20,P21
CLK
P29
Cardreader
CONN.
Cardreader
MINI-SSD
P24
LVDS/CCD/MIC
Con.
USB-8 Int. MIC
P22
INT_LVDS
USB-9
P29
USB3 Port
MB side
USB2.0
USB2-8
CCD(Camera)
P22
USB3.0/2.0
USB Board
Connector
P31
USB2-1,3
eDP
Display
DIS._HDMI DIS._CRT
DIS._eDP
DIS._LVDS
INT._eDP
P29
USB Charger
SATA
SATA5
GPU

Acer Aspire V3-471 Specifications

General

Optical Drive	DVD-Super Multi DL drive
Processor	Intel Core i3/i5/i7 (depending on model)
RAM	4GB DDR3
Storage	500GB HDD
Display	14-inch HD (1366x768)
Graphics	Intel HD Graphics 3000
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion
Weight	2.1 kg
Dimensions	342 x 245 x 25.4 mm
Ports	HDMI, VGA, Ethernet, headphone/microphone combo jack
Wireless	802.11b/g/n
