34902A 16-Channel Multiplexer
Reference
Designator
Part
Number
Qty Part Description
Mfr
Code
Mfr Part Number
C101-C104 0160-7798 4 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C105-C112 0160-5967 8 CAP-FXD 100PF 5% 0805 03292 0160-5967
C113 0160-7828 1 CAP .1UF 16V 10% X7R 02010 0603C104KAT
C120 0160-5947 1 CAP-FXD 1000pF 50 V 02010 08055C102KATA
C125 0160-7845 2 CAP FXD 180PF +-5% 50 V CER COG 12340 C0603C181J5GAC
C127 0160-7845 CAP FXD 180PF +-5% 50 V CER COG 12340 C0603C181J5GAC
C140-C141 0160-5945 7 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C150 0180-4545 1 CAP-FXD 4.7uF +-20% 20 V TA 12340 T491B475M020AS
C151-C152 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C160-C162 0160-7708 3 CAP-FXD 1000pF +-5% 50 V CER C0G 12340 C0805C102J5GAC
C212-C214 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
CR102 1906-0395 11 DIODE-DUAL 75V TO-253 02910 BAS28
CR104 1902-1574 2 DIODE-ZNR 6.8V 6% TO-236 (SOT-23) 02910 BZX84C6V8
CR106 1902-1574 DIODE-ZNR 6.8V 6% TO-236 (SOT-23) 02910 BZX84C6V8
CR107 1906-0291 1 DIODE-DUAL 70V 100MA T0-236AA 02910 BAV99
CR201-CR210 1906-0395 DIODE-DUAL 75V TO-253 02910 BAS28
CR211 1902-1572 1 DIODE-ZNR 15V 5% TO-236 (SOT-23) PD=.35W 02910 BZX84-C15
J101 1252-8024 1 CONN-POST TYPE .100-PIN-SPCG-MTG-END 05525 26-8477-048-002-025
J401-J403 0360-2624 3 CONN TERMINAL BK RA FEM 12PIN 13389 M1.040.0001.9
K301-K316 0490-1897 19 RELAY-REED 2A 1A 300VDC 5VDC-COIL 04501 3500-0113
K326-K328 0490-1897 RELAY-REED 2A 1A 300VDC 5VDC-COIL 04501 3500-0113
L101-L102 9170-1663 3 CORE-SHIELDING BEAD 11702 FBM4532HM132
L104 9170-1584 10 CORE-SHLD BEAD 09808 25Z0805-0SR
L109-L115 9170-1584 CORE-SHLD BEAD 09808 25Z0805-0SR
L150 9170-1584 CORE-SHLD BEAD 09808 25Z0805-0SR
L152 9170-1584 CORE-SHLD BEAD 09808 25Z0805-0SR
L300 9170-1663 CORE-SHIELDING BEAD 11702 FBM4532HM132
L301-L302 9140-1638 2 INDUCTOR 10UH +10% -10%
2.7W-MMX3.4LG-MM
06352 NLC322522T-100K
MP1 34901-60001 KIT, MODULE COVER, CASE 02362 34901-60001
Chapter 7 Replaceable Parts
34902A 16-Channel Multiplexer
