Agilent Technologies 34970A Service Guide

34907A Multifunction Module
Reference
Designator
Part
Number
Qty Part Description
Mfr
Code
Mfr Part Number
C101-C102 0160-7798 17 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C103 0160-5945 9 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C104-C105 0160-7798 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C106-C108 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C110-C112 0160-5967 9 CAP-FXD 100pF +-5% 50 V CER C0G 03292 0160-5967
C120 0160-5947 4 CAP-FXD 1000pF 50 V 02010 08055C102KATA
C140 0160-7798 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C150 0180-4545 1 CAP-FXD 4.7uF +-20% 20 V TA 12340 T491B475M020AS
C203 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C204 0160-7798 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C205 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C206-C207 0160-7798 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C208 0180-4287 6 CAP-FXD 10uF +-20% 35 V TA 05524 293D106X0035D2W
C211-C214 0160-5967 CAP-FXD 100pF +-5% 50 V CER C0G 03292 0160-5967
C301 0160-7798 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C302 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C401 0160-7798 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C402 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C502-C505 0160-7798 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C506 0160-5945 CAP-FXD 0.01uF 50 V 02010 08055C103KATA
C507-C508 0160-7798 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C510 0180-4116 1 CAP-FXD 22uF 20 V TA 00039 NRD226M20R12
C511 0160-6218 1 CAP-FXD 4700pF 50 V 12473 0160-6218
C512 0160-5944 1 CAP-FXD 0.047uF 50 V 12473 0160-5944
C513-C514 0180-4287 CAP-FXD 10uF +-20% 35 V TA 05524 293D106X0035D2W
C515-C516 0180-3751 2 CAP-FXD 1uF +-20% 35 V TA 00039 NRS105M35R8
C520 0180-4287 CAP-FXD 10uF +-20% 35 V TA 05524 293D106X0035D2W
C521 0180-3744 1 TANT SMD 4.7 20% 00039 NRS475M10R8
C522 0160-7798 CAP 0.1UF 50V 10% X7R 0805 02010 08055C104KAT_A
C523-C524 0180-4287 1 CAP-FXD 10uF +-20% 35 V TA 05524 293D106X0035D2W
C531 0160-5967 CAP-FXD 100pF +-5% 50 V CER C0G 03292 0160-5967
C532 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KATA
C533 0160-5967 CAP-FXD 100pF +-5% 50 V CER C0G 03292 0160-5967
C534 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KATA
C550-C551 0160-7733 2 CAP-FXD 100pF +-1% 50 V CER C0G 12340 C0805C101F5GAC
C552 0160-5947 CAP-FXD 1000pF 50 V 02010 08055C102KATA
7
Chapter 7 Replaceable Parts
34907A Multifunction Module
209
