Allen-Bradley 20F Installation Instructions

Rockwell Automation Publication 750-IN001P-EN-P - April 2017 179
Power Wiring Chapter 4
Table 20 - 400 Volt AC and 540 Volt DC Input Protection Devices – Floor Mount Frames 8…10
Applied Rating
(1)
Frame
Cont. Output Amps
Duty Catalog
Number
Output Overload Amps
Continuous AC Input
AC Input Integral Semiconductor Fuse Size (170M)
(2)
DC Bay to Bay Integral Semiconductor Fuse Size (170M)
AC Input Protection Devices Recommended for Branch Circuit Protection (Does not apply to 21G Drives with Options)
Input Quantities
DC Input Integral Semiconductor Fuse Size (170M)
(8)
Dual Element Time Delay Fuse
Non-Time Delay Fuse Circuit
Breaker Max Size
(6)
Motor Circuit Protector
(7)
Continuous DC Input
1 min 3 sec Amps Amps Amps 1/Phase
Min
(4)
2/Phase Min
(4)
Max
(5)
1/Phase Min
(4)
2/Phase Min
(4)
Max
(5)
Amps Amps
400V AC Input 540V DC Input 200 kW 8
385 Heavy 20G…C460 578 693 380 1100 – 500 – 850 500 – 1100 1100 500 443 1600
250 kW 8 460 Normal 20G…C460 506 693 455 1100 – 600 – 1000 600 – 1300 1300 600 529 1600
456 Heavy 20G…C540 684 821 450 1100 – 600 – 1000 600 – 1300 1300 600 525 1600
472 Heavy 20G…C567 708 851 466 1100 – 600 – 1000 600 – 1400 1400 600 543 1600
315 kW 8
540 Light 20G…C460 594 – 534 1100 – 700 350 1200 700 350 1600 1600 700 621 1600
540 Normal 20G…C540 594 821 533 1100 – 700 350 1200 700 350 1600 1600 700 621 1600
540 Heavy 20G…C650 810 975 533 1100 – 700 – 1200 700 – 1600 1600 700 621 1600
315 kW 8 585 Light 20G…C540 644 – 578 1100 – 750 375 1300 750 375 1700 1700 800 673 1600
567 Normal 20G…C567 624 851 560 1100 – 750 375 1200 750 375 1700 1700 700 652 1600
585 Heavy 20G…C750 878 1125 577 1100 – 750 375 1300 750 375 1700 1700 800 673 1600
355 kW 8
612 Light 20G…C567 673 – 604 1100 – 800 400 1300 800 400 1800 1800 800 704 1600
650 Normal 20G…C650 715 975 640 1100 – 850 425 1400 850 425 1900 1900 800 748 1600
642 Heavy 20G…C770 963 1155 634 1100 – 800 400 1400 800 400 1900 1900 800 739 1600
400 kW 8 750 Light 20G…C650 825 – 739 1100 – 1000 500 1600 1000 500 2200 2200 1000 863 1600
750 Normal 20G…C750 825 1125 739 1100 – 1000 500 1600 1000 500 2200 2200 1000 863 1600
770 Normal 20G…C770 847 1155 758 1100 – 1000 500 1700 1000 500 2300 2300 1000 886 1600
450 kW 8
796 Light 20G…C750 876 – 784 1100 – 1000 500 1700 1000 500 2300 2300 1000 916 1600
832 Light 20G…C770 915 – 819 1100 – 1100 550 1800 1100 550 2400 2400 1200 957 1600
400 kW 9
750 Heavy 20G…C910 1125 1365 739 1100 1400
(3)
900 450 1700 900 450 2200 2200 900 863 1600
(3)
500 kW 9 880 Heavy 20G…C1K0 1320 1584 867 1100 1400
(3)
1100 550 2000 1100 550 2600 2600 1100 1013 1600
(3)
910 Heavy 20G…C1K1 1365 1638 896 1100 1400
(3)
1100 550 2000 1100 550 2700 2700 1100 1047 1600
(3)
910 Normal 20G…C910 1001 1365 896 1100 1400
(3)
1100 550 2000 1100 550 2700 2700 1100 1047 1600
(3)
560 kW 9 1040 Light 20G…C910 1144 – 1024 1100 1400
(3)
1300 650 2300 1300 650 3100 3100 1300 1197 1600
(3)
1040 Normal 20G…C1K0 1144 1584 1024 1100 1400
(3)
1300 650 2300 1300 650 3100 3100 1300 1197 1600
(3)
1040 Heavy 20G…C1K2 1560 1872 1024 1100 1400
(3)
1300 650 2300 1300 650 3100 3100 1300 1197 1600
(3)
630 kW 9 1090 Light 20G…C1K0 1199 – 1073 1100 1400
(3)
1350 675 2400 1350 675 3200 3200 1350 1254 1600
(3)
1090 Normal 20G…C1K1 1199 1638 1073 1100 1400
(3)
1350 675 2400 1350 675 3200 3200 1350 1254 1600
(3)
1090 Heavy 20G…C1K4 1635 2198 1073 1100 1400
(3)
1350 675 2400 1350 675 3200 3200 1350 1254 1600
(3)
