Rockwell Automation Publication 1756-UM001M-EN-P - February 2012 181
Using the PhaseManager Tool Chapter 11
Equipment Phase
Instructions
The controller supports several equipment-phase relay ladder and structured text
instructions.
For more information about instructions for use with equipment phases, see the
PhaseManager User Manual, publication LOGIX-UM001
.
Additional Resources
These documents contain additional information concerning related Rockwell
Automation products.
You can view or download publications at http://www.rockwellautomation.com/
literature. To order paper copies of technical documentation, contact your local
Rockwell Automation distributor or sales representative.
Table 49 - Instructions for Use with PhaseManager Tool
Instruction Instruction Function
PSC Signal a phase that the state routine is complete and to proceed to the next state.
PCMD Change the state or substate of a phase.
PFL Signal a failure for a phase.
PCLF Clear the failure code of a phase.
PXRQ Initiate communication with RSBizWare™ Batch software.
PRNP Clear the NewInputParameters bit of a phase.
PPD Set up breakpoints within the logic of a phase.
PATT Take ownership of a phase to either of the following:
• Prevent another program or RSBizWare Batch software from commanding a
phase.
• Make sure another program or RSBizWare Batch software does not already own
a phase.
PDET Relinquish ownership of a phase.
POVR Override a command.
Resource Description
PhaseManager User Manual, publication LOGIX-UM001
Provides steps, guidance, and examples for setting up and programming a Logix5000
controller to use equipment phases.
