Rockwell Automation Publication 1756-UM001M-EN-P - February 2012 83
Chapter 4
ControlLogix System and Controllers
The ControlLogix System
The ControlLogix system is chassis-based and provides the option to configure a
control system that uses sequential, process, motion, and drive control in addition
to communication and I/O capabilities.
Configuration Options
This section describes some of the many system configuration options that are
available with ControlLogix controllers.
Standalone Controller and I/O
One of the simplest ControlLogix configurations is a standalone controller with
I/O assembled in one chassis.
Figure 3 - Standalone Controller and I/O
Topic Page
The ControlLogix System 83
Design a ControlLogix System 86
ControlLogix Controller Features 87
Additional Resources 89
L75
Input
Output
Output
32044-MC
To Next Page
