Page #208 background imageLoading...
Page #208 background image
206 Rockwell Automation Publication 1756-UM001M-EN-P - February 2012
Appendix A Status Indicators
1756-L7x Controller Status
Indicators
The status indicators are below the status display on the controller. They indicate
the state of the controller as described in these tables.
#FD0A Axis Attribute Reject
#FD1F Safety I/O
#FD20 No Safety Task
#FE01 Invalid Connection Type
#FE02 Invalid Update Rate
#FE03 Invalid Input Connection
#FE04 Invalid Input Data Pointer
#FE05 Invalid Input Data Size
#FE06 Invalid Input Force Pointer
#FE07 Invalid Output Connection
#FE08 Invalid Output Data Pointer
#FE09 Invalid Output Data Size
#FE0A Invalid Output Force Pointer
#FE0B Invalid Symbol String
#FE0C Invalid Scheduled P/C Instance
#FE0D Invalid Symbol Instance
#FE0E Module Firmware Updating
#FE0F Invalid Firmware File Revision
#FE10 Firmware File Not Found
#FE11 Firmware File Invalid
#FE12 Automatic Firmware Update Failed
#FE13 Update Failed - Active Connection
#FE14 Searching Firmware File
#FE22 Invalid Connection Type
#FE23 Invalid Unicast Allowed
#FF00 No Connection Instance
#FF01 Path Too Long
#FF04 Invalid State
#FF08 Invalid Path
#FF0B Invalid Config
#FF0E No Connection Allowed
Table 57 - I/O Fault Messages
Code Message
