Rockwell Automation Publication 1756-UM001M-EN-P - February 2012 65
Start Using the Controller Chapter 3
Use RSLogix 5000 Software to Change the Operation Mode
Depending on the mode of the controller you specify by using the mode switch,
you can change the Operation mode of the controller using RSLogix 5000
software.
After you are online with the controller and the controller mode switch is set to
Remote (REM or the center position), you can use the Controller Status menu in
the upper-left corner of the RSLogix 5000 software window to specify these
operation modes:
• Remote Program
• Remote Run
• Remote Test
Operation Mode via RSLogix 5000 Software
For this example, the controller mode switch is set to Remote mode. If your
controller mode switch is set to Run or Program modes, the menu options
change.
