226 Math Instructions
The RAD instruction converts the Source (in degrees) to radians and
stores the result in the Destination.
The following formula applies:
Source * Î /180
where Î = 3.141592
Enter the following parameters when programming this instruction:
• Source is the address to compute the radians.
• Destination is the address to store the radians of the Source.
Address Levels for the operands involved in the RAD can be ALL word,
ALL double word, ALL float, or a combination. These operands shall
undergo a conversion to float. The calculation of the source (in float) is
then performed, and the result is then cast to the data type of Destination.
Instruction Operation
When the rung is true, this instruction shall convert the Source (in
degrees) in radians and place the result in Destination.
If the Destination is floating point, the result shall always be rounded
using the round to even rule.
RAD Instruction Valid Addressing Modes and File Types
For definitions of the terms used in this table see Using the Instruction Descriptions on page 92.
Parameter
Data Files
Function Files
(1)
CS - Comms
IOS - I/O
DLS - Data Log
(2)
Address Mode
(3)
Address Level
O
I
S
B
T, C, R
N
F
ST
L
MG, PD
RI/RIX
PLS
RTC
HSC
PTOX, PWMX
STI
EII
BHI
MMI
LCD
Direct
Indirect
Immediate
Int16
Immediate Int32
Immediate Float
Bit
Word
Double Word
Element
Float
Source •• •••• • • • • • • • ••••
Destination • • • • • • • •
• • •• •
(1) PTOX and PWMX files are only for use with MicroLogix 1400 BXB or BXBA unit.
(2) The Data Log Status file can only be used for the following math instructions: ADD, SUB, MUL, DIV, NEG, and SCP.
(3) See Important note about indirect addressing.
IMPORTANT
You cannot use indirect addressing with: S, MG, PD, RTC, HSC, PTOX,
PWMX, STI, EII, BHI, MMI, CS, IOS, and DLS files.
