39 Publication 1766-RM001A-EN-P - October 2008

Chapter

Controller Memory and File Types

This chapter describes controller memory and the types of files used by

the MicroLogix 1400 controller. The chapter is organized as follows:

• Controller Memory on page 40

• Data Files on page 45

• Protecting Data Files During Download on page 47

• Static File Protection on page 49

• Password Protection on page 50

• Clearing the Controller Memory on page 51

• Allow Future Access Setting (OEM Lock) on page 52

• Web View Disable on page 52
