Publication 1766-RM001A-EN-P - October 2008

622 Protocol Configuration

87 Negative Acknowledge The slave cannot perform the program function received in the

command.

88 Memory Parity Error The slave attempted to read extended memory, but detected a

parity error in the memory.

89 Non-standard Error Code An error code greater than 8 was returned by the slave. >8

Modbus Error Codes in Modbus RTU Master MSG Instruction

Error

Code

Error Description Received

Exception Code
