Allen-Bradley PowerFlex 70 User Manual

58 Rockwell Automation Publication 20A-UM001N-EN-P - July 2013
Chapter 1 Programming and Parameters
UTILITY (file E)
Diagnostics
234
236
[Testpoint 1 Sel]
[Testpoint 2 Sel]
Selects the function whose value is displayed
value in [Testpoint x Data].
These are internal values that are not accessible
through parameters.
See Testpoint Codes and Functions on page 85
for a listing of available codes and functions.
Default:
Min/Max:
Units:
499
0/999
0/65535
1
235
237
235
237
[Testpoint 1 Data]
[Testpoint 2 Data]
The present value of the function selected in
[Testpoint x Sel].
Default:
Min/Max:
Units:
Read Only
0/65535
±2147483647
1
234
236
Faults
238 [Fault Config 1]
Enables/disables annunciation of the listed faults.
(4)
Bit 11 enables the shear pin fault to be ignored during acceleration and deceleration. If you use Bit 11 with
Bit 4 set to “0”, Bit 11 will have no effect.
189
240 [Fault Clear]
Resets a fault and clears the fault queue.
Default:
Options:
0
0
1
2
“Ready”
“Ready”
“Clear Faults”
“Clr Flt Que”
241 [Fault Clear Mode]
Enables/disables a fault reset (clear faults)
attempt from any source. This does not apply to
fault codes that are cleared indirectly via other
actions.
Default:
Options:
1
0
1
“Enabled”
“Disabled”
“Enabled”
242 [Power Up Marker]
Elapsed hours from the initial drive powerup.
This value rolls over to 0 after the drive has been
powered on for more than the max value
shown. The parameter value only updates at
powerup. For relevance to most recent power
up see [Fault x Time] on page 59
.
Default:
Min/Max:
Units:
Read Only
0.0000/429496.7295 Hrs
0.0001 Hrs
246
File E Group No.
Parameter Name and Description
See page 14 for symbol descriptions
Values
Related
E C
32
E C
E C
11
1
0001000x0xxxx
10 01234567891112131415
1 = Enabled
0 = Disabled
x = Reserved
Bit #
Factory Default Bit Values
Power Loss
UnderVoltage
Motor OverLd
Shear Pin
AutRst Tries
Decel Inhibt
Motor Therm
(1)
(3)
In PhaseLoss
(2)
Load Loss
(2)
ShearPNo Acc
(1)(3)
Nibble 1Nibble 2Nibble 3Nibble 4
(1)
Enhanced firmware 1.001 & later.
(2)
Enhanced firmware 2.001 & later.
(3)
Enhanced firmware 4.001 & later.
HS Low Temp
