Allied Telesis AT-8000S Switch
Web Browser Interface User’s Guide
– Fault — Indicates that the device has detected a fault on the powered device. For example, the powered
device memory could not be read.
• Nominal Power — Indicates the actual amount of power the device can supply. The field value is displayed
in Watts.
• Consumed Power — Indicates the amount of the power used by the device. The field value is displayed in
Watts.
• System Usage Threshold — Indicates the percentage of power consumed before an alarm is generated.
The value range is 1-100 percent; the default value is 95 percent. At the default setting of 95%, the threshold
is exceeded when the PoE devices require more than 380 W, which is 95% of 400 W.
• Traps — Indicate if PoE device traps are enabled.
The Zoom View shows device ports and indicators of current PoE port status. The possible port settings are:
2. Click the ports to enable. Clicking a port toggles it through the possible settings.
3. Define the fields.
4. Click Apply. PoE is enabled on the device and global settings are saved. The new threshold is immediately
activated on the device.
5. Click Save Config on the menu to permanently save the change.
Defining PoE Settings
To modify PoE port settings:
1. In the Power Over Ethernet Page Zoom View, click the port(s) to modify. The port indication changes to Port
is selected.
2. Click Modify. The Modify PoE Page opens:
Port is active — Indicates the port is linked.
Port is inactive — Indicates the port is not linked.
Port is disabled — Indicates the port is disabled.
Port is selected — Indicates the port is selected.
