Shift the ECU and the protection.

•

Remove the ECU protection.

•

Disconnect the connector and remove

the control unit.

NOTE

WHEN REFITTING THE CONNECTORS, THE SLIDES MUST

MOVE FREELY TO THE END OF STROKE, WHICH HELPS

WITH THE INSERTION OF THE CONNECTOR: YOU MUST

HEAR THE RELEASE OF THE RETAINING TANG AT THE

END OF STROKE.

See also

Fuel tank

Air box

Electrical system DORSODURO 1200 ABS - ATC

ELE SYS - 126
