INSTRUMENT PANEL

pos. Description Type Quantity Torque Notes

1 TCEI screw fastening instrument

panel mounting to fork yoke

M6x20 2 10 Nm (7.37 lbf ft) -

2 Screw fixing instrument panel to

plate

5x14 3 2.6 Nm (1.92 lbf ft) -

DORSODURO 1200 ABS - ATC Characteristics

CHAR - 19
