FUEL PUMP

pos. Description Type Quantity Torque Notes

1 TEFL screw fastening fuel pump M5x16 6 3 Nm (2.21 lbf ft) Loctite 518

2 TEFL screw fastening fuel pipe M6x16 1 10 Nm (7.37 lbf ft) -

AIR FILTER BOX

pos. Description Type Quantity Torque Notes

1 Cross head self-tapping screw fas-

tening covers / filter box

M5x20 10 3 Nm (2.21 lbf ft) -

2 Cross head self-tapping screw fas-

tening blow-by tank

M5x20 2 3 Nm (2.21 lbf ft) -

Characteristics DORSODURO 1200 ABS - ATC

CHAR - 30
