pos. Description Type Quantity Torque Notes
6 Decompression device fixing screw torx M8 2 28.5 Nm (21.02 lbf ft) 3M SCOTCH GRIP
2353
7 Fastener screw M5 2 5.50 Nm (4.06 lbf ft) 3M SCOTCH GRIP
2353
CRANKSHAFT
pos. Description Type Quantity Torque Notes
1 Crankshaft primary gear fastener nut M24x1.5 1 300 Nm (221.27 lbf ft) Anticlockwise nut
2 Connecting rod screw M10 4 15 + 30 Nm (11.06 +
22.13 lbf ft) + 50° ± 2°,
final control torque 65 -
78 Nm (47.94 - 57.53 lbf
ft)
Lubricate the
threads before tight-
ening
Characteristics DORSODURO 1200 ABS - ATC
CHAR - 46
