Drive chain
DRIVE CHAIN
Specification Desc./Quantity
Type Endless (without master link) and with sealed links. No. of links
108
Model 525 ZRPK
Electrical system
ELECTRICAL SYSTEM
Specification Desc./Quantity
Battery 12 V - 12 Ah YTX 14 - BS
Main fuses 30A
Auxiliary fuses 7.5 A; 10 A; 15 A
ABS - ATC fuses (if fitted) 20 A
Alternator (permanent magnet type) 13.5 V - 450 W at 6000 rpm
SPARK PLUGS
Specification Desc./Quantity
Standard spark plugs NGK CR8EKB
Alternative spark plugs, for sports use or for prolonged high
speed cruising fully loaded
NGK CR9EKB
Spark plug electrode gap 0.6 - 0.7 mm (0.024 - 0.028 in)
Resistance 5 kOhm
WARNING LIGHTS
Specification Desc./Quantity
High beam light LED
Right turn indicator LED
Left turn indicator LED
General warning LED
Gear in neutral LED
Side stand down LED
Fuel reserve LED
ABS LED
BULBS
Specification Desc./Quantity
High beam light 12 V - 60 W H4
Low beam light 12 V - 50 W H4
Front daylight running light 12V - 6W H6
Turn indicator light 12V - 10W
Rear daylight running light / stop light LED
License plate light 12V - 5W
Rpm indicator lighting LED
Multifunction display lighting LED
Frame and suspensions
CHASSIS
Specification Desc./Quantity
Type Component chassis (bolted). Die-cast aluminium plates and
high-strength steel tubular chassis.
Steering inclination angle 27.3°
Trail 118 mm (4.65 in)
Characteristics DORSODURO 1200 ABS - ATC
CHAR - 14
