APRILIA DORSODURO 1200 ABS - ATC User Manual

•
on the vehicle: left side, under the filter box
•
connector: on the sensor
Electrical characteristics:
•
Not detected by a multimeter as they are contactless: read the voltage of the 4 tracks by the
diagnosis instrument.
MASTER connector (blue)
•
A: Track A supply
•
B: Track A ground
•
C: Track A signal
•
D: Track B supply
•
E: Track B ground
•
F: Track B signal
SLAVE connector (white)
•
A: Track C supply
•
B: Track C ground
•
C: Track C signal
•
D: Track D supply
•
E: Track D ground
•
F: Track D signal
DIAGNOSIS INSTRUMENT: PARAMETERS
Blue front connector throttle grip position sensor - track A
•
Example value with key ON: 1107 mV
•
Example value with engine on: -
Voltage value of the front potentiometer - track A
Blue front connector throttle grip position sensor - track B
•
Example value with key ON: 1070 mV
•
Example value with engine on: -
Voltage value times 2 of the front potentiometer track B
White rear connector throttle grip position sensor - track C
•
Example value with key ON: 3560 mV
•
Example value with engine on: -
Voltage value of the rear potentiometer track C
White rear connector throttle grip position sensor - track D
•
Example value with key ON: 3555 mV
•
Example value with engine on: -
Voltage value times 2 of the rear potentiometer track D
DORSODURO 1200 ABS - ATC Electrical system
ELE SYS - 139
