between PIN 26 and 27 of the instrument panel: approximately 120 Ohm
Pin out:
•
Line L: Orange cable between Marelli control unit PIN 66 and the black-bodied connector
PIN 27 of the instrument panel.
•
Line H: White/Black cable between Marelli control unit PIN 80 and the black-bodied con-
nector PIN 26 of the instrument panel.
CAUTION
BEFORE CARRYING OUT ANY TROUBLESHOOTING, CAREFULLY READ THE GENERAL TROU-
BLESHOOTING CONCEPTS FOR ELECTRICAL DEVICES AT THE BEGINNING OF THE CHECK
AND CONTROL SECTION IN THE ELECTRICAL SYSTEM CHAPTER.
DIAGNOSIS INSTRUMENT: ELECTRICAL ERRORS
CAN line "Mute Node" U1601
•
Mute Node.
Error cause
•
The injection ECU cannot send CAN signals; it receives signals from the instrument panel
and the ABS control unit (if any): the control unit may need replacing.
Troubleshooting
•
Replace the Marelli control unit.
CAN line without signals U1602
•
Bus Off.
Error cause
•
No communication on CAN line (PIN 66 and/or PIN 80): problem on the whole network (for
example, battery cut-off or short circuited or shorted to ground).
Troubleshooting
•
Check the Marelli control unit VEHICLE connector: if not OK, restore; if OK, check the ground
insulation of the two CAN lines from PIN 66 and PIN 80 of the VEHICLE connector: if not
OK, restore cable harness; if OK, check the continuity of the two CAN lines from Marelli
control unit VEHICLE connector to the instrument panel connector: if not OK, restore the
cable harness; if OK, check that the two lines are not shorted to positive testing each of the
2 connectors (Marelli control unit and instrument panel connector) with 1 connector discon-
nected at a time and by setting the key to ON: If not OK, restore; if OK, replace the Marelli
control unit.
CAN line towards instrument panel U1701
•
no signal.
Error cause
•
No signal is received from the instrument panel.
Troubleshooting
Electrical system DORSODURO 1200 ABS - ATC
ELE SYS - 190
