Splitting the

crankcase halves

•

Slide off the desmodromic drum con-

trol.

•

Remove the three gear selection forks.

CAUTION

THE MAIN SHAFT FORK IS SMALLER THAN THOSE OF

THE SECONDARY SHAFT.

ALL THE SECONDARY SHAFT FORKS ARE THE SAME

SIZE.

DORSODURO 1200 ABS - ATC Engine

ENG - 213
