Collect the washer.

NOTE

REPLACE THE WASHER ON EVERY SERVICING

•

Heat the screws of the gearbox selec-

tor mounting plate.

•

Unscrew and remove the three screws

fastening the gearbox selector mount-

ing plate.

•

Remove the plate complete with selec-

tor

Engine DORSODURO 1200 ABS - ATC

ENG - 216
