To Next Page

To Previous Page

•

Unscrew and remove the two screws.

•

Remove the chain tensioner and col-

lect the gasket.

•

Remove the camshafts with the gears.

See also

Removing camshafts

Magneto flywheel

removal

•

Unscrew and remove the two chain

slider screws.

•

Unscrew and remove the chain inter-

mediate gear pin.

•

Pay attention to avoid damaging the O-

ring.

DORSODURO 1200 ABS - ATC Engine

ENG - 251
