Compress the valve springs with the

specific wrench and with the spring

compressing tool.

Specific tooling

020382Y Tool for removing valve cotters fitted

with part 012

020896Y Bushing for valve removal

•

Remove the cotters using a magnet.

•

Release the valve springs.

•

Remove the valve spring fittings and

the springs.

DORSODURO 1200 ABS - ATC Engine

ENG - 255
