Coolant replacement

•

Release the clamp retaining the

breather pipe to radiator.

NOTE

UPON REFITTING, ALWAYS REPLACE WITH A NEW

CLAMP.

•

Operating from the right side, unscrew

and remove the radiator upper screw.

•

Disconnect the left electric fan.

•

Unscrew and remove the screw of the

expansion tank.

Cooling system DORSODURO 1200 ABS - ATC

COOL SYS - 374
