In the Event of a Fire Alarm
Operator's Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME-OPERATE/FGB Rev. B, 2009-10-28,
Autronica Fire and Security AS
Page 27
5. In the Event of a Fire Alarm
5.1 Indications in the Event of a Fire Alarm
The red Alarm indicator is pulsing.
The total number of Detection
Zones.
The text display presents the first
and last (if several) detection
zones in alarm state and their
location. By operating the menu,
detailed information is available.
The red More Events indicator is
pulsing if several detection zones
are signaling a Fire Alarm.
The internal buzzer is activated.
The fire alarm condition activates
Fire Alarm Devices (sounders,
bells, visual indicators, etc.).
5.2 Actions to be Taken in the Event of a Fire Alarm
Step Actions to be taken Display Indication Audible Indication
1
Follow all precautions
described in the local
fire instructions, step by
step.
All fire alarm devices
connected to the
alarm zones (which
are connected to the
detection zones in
alarm) are activated
(sounders and visual
indicators).
The internal buzzer on
the operator panel is
turned on.
Comments: The first detection and last detection zone (if several) and points in alarm are
highlighted in the display. The total number of detection zones in alarm state
is shown in the uppermost right corner of the display.
The red Alarm indicator is pulsing. If an output to Fire Alarm Routing
Equipment is configured and applied, the red Remote Call indicator will also
be pulsing.
When several zones are in alarm state, the More Events indicator is pulsing.
2
To silence the internal
buzzer, press the black
Mute Panel button.
The internal buzzer on
the operator panel is
turned off.
One or several fire detectors or manual call-points in one or several detection zones
are signalling a Fire Alarm.
Only the operating buttons that are available and
relevant to the current state are backlit.
