Show Unit Properties
Operator's Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME-OPERATE/FGB Rev. B, 2009-10-28,
Autronica Fire and Security AS
Page 57
14.3 Detection Zones
Using the Enter button after selecting a detection zone reveals
the following properties:
name of the detection zone
alarm organization:
o Immediate Action Detection Zone
o Dependency Action Detection Zone
o Delayed Action Detection Zone
o Delayed Dependency Detection Zone
o SOLAS (Safety of Life at Sea) Detection Zone
Using the Function button
after selecting a detection zone gives
the following menu selections:
Show Member Points
Show Connected Units
14.4 Alarm Zones
The top-level Alarm Zone (default) is called the Parent Alarm Zone. A
system consists of a Parent Alarm Zone, usually with several “sub-
level” alarm zones in an hierarchy. Each “sub level”-alarm zone is
related to a specific area of, for example, a building. If an alarm occurs
in a Parent Alarm Zone, all Fire Alarm Devices (FADs) within the
Parent Alarm Zone, plus all FADs belonging to all “sub-level”-alarm
zones will be activated.
Using the Enter button
after selecting an alarm zone reveals the
following properties:
name of the Alarm Zone
Using the Function button
after selecting an alarm zone gives the
following menu selections:
Show Member Fire Alarm Devices
Show Neighbour Alarm Zones
Show Activating Detection Zones
