Operator's Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME-OPERATE/FGB Rev. B, 2009-10-28,
Autronica Fire and Security AS
Page 40
9. Supervisory
9.1 Indications during Supervisory
The Supervisory indicator has a
steady yellow light.
The text display indicates the
activation of an input device. By
operating the menu, detailed
information is available.
The internal buzzer is activated.
9.2 Actions to be Taken during Supervisory
Step Actions to be
taken
Display Indication Audible Indication
1
Notify
service/technical
personnel if
necessary.
The internal buzzer on
the operator panel is
turned on.
Comments: The yellow Supervisory indicator is pulsing.
2
To silence the internal
buzzer, press the
black
Mute Panel button.
The internal buzzer on
the operator panel is
turned off.
Comments: In this example, one point is in a Supervisory state.
3
Use the arrow down
button to scroll
downwards
The system indicates the activation of an input device, for example, a door control unit.
Only the operating buttons that are available and
relevant to the current state are backlit.
