The Operator Panel - Overview
Operator's Handbook, AutroSafe Interactive Fire Alarm System, Release 3, ASAFE-FO/FE Rev. E, 021105,
Autronica Fire and Security AS
Page 13
2.4.4 Utility Buttons
Utility Buttons
Button Designation
i
Help The Help button allows you to get useful information quickly while
operating the system. You can look up information on how to
operate the panel. NOT YET IMPLEMENTED.
!
Menu Used to switch between Operation Mode and Menu Mode.
Operation Mode (operate !) >> Menu Mode (operate ! or time-
out) >> Operation Mode.
Close Used to move back one level / show previous picture if the display is
not showing information on the top level.
2.5 Internal Buzzer
Each operator panel provides a buzzer which is activated as described
below. Each condition may have its own sound pattern. If more than
one condition is present simultaneously, the state of the operator panel
and the buzzer signal will be decided. The buzzer will reflect the
condition which has the highest priority.
The internal buzzer is controlled by hardware. It is activated in the
cases of:
• System Fault
• Alarm
• Prealarm
• Fault
• Early Warning (not yet implemented)
The buzzer can be silenced by pressing the Mute Panel button. One
exception is the buzzer signal indicating System Fault which can not
be silenced.
If the reason for the buzzer signal still exists, the buzzer will resound
after a predefined time.
