Operation Mode
Operator's Handbook, AutroSafe Interactive Fire Alarm System, Release 3, ASAFE-FO/FE Rev. E, 021105,
Autronica Fire and Security AS
Page 19
3.8 Action Digits in Operation Mode
When operating in Operation Mode, special Action Digits will appear in
the highlighted field (Information Field) at the lower part of the display.
These digits show at any time which action the operator may perform.
1
ABC
2
DEF
3
GHI
4
JKL
Figure 3-5: Action Digits in Operation Mode
For example, digit 1 in the event of a fire alarm (after silencing alarms)
represents RESOUND.
The example below shows a situation where Action Digit 4 (SHOW
SUPPR. INFO = suppressed information) is available.
1 OFFICES
2 WORKSHOP
3 CANTEEN
FIRE ALARMS
19:23
Total: 3
4: SHOW SUPPR. INFO
Action Digit
Figure 3-6: Action Digits shown in the Information Field
In Appendix you will find a table providing a complete list of all Action
Digits that may appear in Operation Mode.
Digits 1 to 4 on the alphanumeric keyboard are dedicated for
the different actions (Action Digits). The type of action
depends on the current state of the system.
