Menu Mode
Operator's Handbook, AutroSafe Interactive Fire Alarm System, Release 3, ASAFE-FO/FE Rev. E, 021105,
Autronica Fire and Security AS
Page 50
9.6.2 Using the Up/Down Arrows in the Selection Field
In this example, we want to select OFFICES by using the up/down
arrows in the selection field.
• Press the ENTER button ( ), then use the arrow buttons to move
up and down. (In this example the first selection KITCHEN is
highlighted and the arrow down button is used to select OFFICES).
DISABLE
19:23
DETECTION ZONES
KITCHEN
CANTEEN
OFFICES
WORKSHOP
Figure 9-4: Using the arrow buttons
• Press the ENTER button to select OFFICES, and use the numeric
buttons to enter numbers in the input field - (to cancel an input
value, press C).
DISABLE
19:23
OFFICES
DETECTION ZONES
Disablement time
Hour :
Min. :
Execute command
02
• When all values have been entered, press the ENTER button to
accept.
