9. Menu Mode
9.1 How to Enter Menu Mode
To enter the Menu Mode from operation mode or the panel’s idle state,
the Menu button (!
!!
! ) must be pressed. The menu has 6 different
menu selections, including SHOW STATUS, DISABLE, ENABLE,
SYSTEM, SERVICE and OUTPUT CONTROL.
9.2 The Menu Mode Display
In Menu Mode the display only needs one window showing the
selected part of the system menu. The information field at the lower
part of the display is reserved to give the operator information on the
different actions that can be performed from the alphanumeric
keyboard (Action Digits), or short fault messages. This field is always
highlighted.
If there is an alarm condition, the last alarm detected and the total
number of present alarms will be shown below the information field.
MENU
19:23
Total: 3
Operator
Information
1 SHOW STATUS
2 DISABLE
3 ENABLE
4 SYSTEM
5 SERVICE
FIRE ALARMS Total: 3
3 CANTEEN
Last alarm detected
Total no.
of alarms
MENU
19:23
Total: 3
Operator
Information
1 SHOW STATUS
2 DISABLE
3 ENABLE
4 SYSTEM
5 SERVICE
FIRE ALARMS Total: 3
3 CANTEEN
Last alarm detected
Total no.
of alarms
Figure 9-1: Menu Mode display
NOTE:
If an alarm condition occurs when you are in Menu Mode,
you have to press the Menu button to re-enter Operation
Mode
in order to activate the Silence Alarms button and the
Reset button.
Main Menu Structure
!
"
Show Status
Disable
Enable
System
Service
Main Menu
To Next Page
