Show Status
Operator's Handbook, AutroSafe Interactive Fire Alarm System, Release 3, ASAFE-FO/FE Rev. E, 021105,
Autronica Fire and Security AS
Page 58
10.7 Show Status - Detection Zones in Test
This menu gives detailed information on the zones in test mode.
The example below describes how to view the current status of zones
in test mode.
Step Actions to be taken Display Indication
1
To enter the Main Menu, press
!
MENU
19:23
Total: 3
1 SHOW STATUS
2 DISABLE
3 ENABLE
4 SYSTEM
5 SERVICE
2
To select SHOW STATUS, press 1.
SHOW STATUS
1 FIRE ALARMS
2 FIRE WARNINGS
3 FAULTS
4 DISABLEMENTS
5 DETECTION ZONES IN TEST
6 OIL&GAS INHIBITED POINTS
7 ACTIVATED OUTPUTS
19:23
3
To select DETECTION ZONES IN TEST, press
5.
4
To move the cursor to the desired selection,
scroll with the arrow buttons
6
PQR
or
9
YZ
5
To view detailed zonal information for the
selected detection zone, press
6
To view point(s) in test for the selected detection
zone, press Action Digit 1 (SHOW POINTS).
7
To return (each step backwards), press
