Rear-wheel stand

Mounting rear-wheel

stands

Park motorcycle, ensuring that

support surface is firm and

level.

Use basic stand with rear

wheel adapter. The basic

stand and its accessories

are available through your

authorized BMW Motorrad

retailer.

Set desired height of rear-

wheel stand using bolts 1.

Remove the lock washer 2; to

do so, press the unlock but-

ton 3.

Push the rear-wheel stand from

the right onto the rear axle.

Apply the retaining disk from

the left; to do so, press the un-

lock button.

Position motorcycle upright

while simultaneously pressing

grip of stand back so that both

stand rollers rest on ground.

Then press the grip down to

the ground.

Engine oil

Check engine oil level

ATTENTION

Misinterpretation of the oil

filling quantity, as the oil

level is temperature-depen-

dent (the higher the tempera-

ture, the higher the oil level)

116

Maintenance

ProCarManuals.com

Questions and Answers:

Need help?

Do you have a question about the BMW R 1200RS 2016 and is the answer not in the manual?

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
