BMW R 1200RS 2016 User Manual

Weights
Vehicle curb weight 520 lbs (236 kg), DIN unladen weight, ready for
road, fuel tank 90 % full, without OE
Permissible gross weight 992 lbs (450 kg)
Maximum payload 472 lbs (214 kg)
Permissible front wheel load max 397 lbs (max 180 kg)
Permissible rear wheel load max 661 lbs (max 300 kg)
Performance data
Start-off capacity on uphill grades (with permissi-
ble total weight)
20 %
Top speed >124 mph (>200 km/h)
11
182
z Technical data
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
