Reposition windshield

The windshield can be fas-

tened on the motorcycle in two

different positions.

To reposition windshield 1, re-

move all screws 2 and take off

windshield.

Position windshield on corre-

sponding hole 3 while watching

bushing 4 (inserted from be-

low) and rubber grommet 5.

Install all four screws 6.

Windshield in bracket

2 lb/ft (2.5 Nm)

Headlight

Headlight range and

spring preload

The headlight range generally

remains constant due to the ad-

justment of the spring preload to

the loading state.

Spring preload adjustment may

only be insufficient when the mo-

torcycle is very heavily loaded.

In this case, the headlight range

must be adjusted to the weight.

NOTICE

If there are doubts as to the cor-

rect headlight range, have the

adjustment checked by a spe-

cialized workshop, preferably by

an authorized BMW Motorrad

retailer.

Setting

ProCarManuals.com

Questions and Answers:

Need help?

Do you have a question about the BMW R 1200RS 2016 and is the answer not in the manual?

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
