Deactivating cruise-
control system
Actuate brakes, clutch or throt-
tle grip (take back throttle be-
yond back position) to deacti-
vate cruise-control system.
NOTICE
When changing gear using the
Pro Gear-shift Assistance func-
tion, the cruise-control system
is automatically deactivated for
safety reasons.
NOTICE
with ASC and DTC interventions,
the cruise-control system is au-
tomatically deactivated for safety
reasons.
Cruise-control system indicator
light goes out.
Resume former cruising
speed
Briefly push button 1 back to
return to the speed saved be-
forehand.
NOTICE
Opening the throttle does not
deactivate the cruise-control sys-
tem. If you release the throttle
grip, the motorcycle will decel-
erate only to the cruising speed
saved in memory, even though
you might have intended slowing
to a lower speed.
Cruise-control system indi-
cator light lights up.
Switch off cruise-control
system
Push switch 1 to left.
The system is deactivated.
Button 2 is locked.
Heated handlebar grips
with heated handlebar grips
OE
4
73
z Operation
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
