BMW R 1200RS 2016 User Manual

Maximum payload and
maximum speed
Observe maximum payload and
maximum speed as indicated on
label in case.
If you cannot find your
combination of motorcycle and
case on the label, contact your
BMW Motorrad Retailer.
The following values apply to the
combination described here:
Maximum speed for rid-
ing with case
max 112 mph (max 180 km/h)
Payload per case
max 22 lbs (max 10 kg)
Secure hold
with Touring case
OA
If a case wobbles or is difficult to
fit, it must be adapted to the gap
between the upper and lower
mount.
WARNING
Improperly installed case.
Impairment of riding safety.
Cases may not shake and must
be fastened play-free. If some
play is determined after longer
use, readjust the retaining
claw.
Use the screws 1 inside the case
for this purpose.
Topcase
Opening topcase
with topcase
OA
9
153
z Accessories
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
