BMW R 1200RS 2016 User Manual

Compression ratio 12.5:1
Rated output 125 hp (92 kW), at engine speed: 7750 min
-1
with power reduction
OE
107 hp (79 kW), at engine speed: 7750 min
-1
Torque 92 lb/ft (125 Nm), at engine speed: 6500 min
-1
with power reduction
OE
90 lb/ft (122 Nm), at engine speed: 5250 min
-1
Maximum engine speed max 9000 min
-1
Idle speed 1150 min
-1
, Engine at operating temperature
Emission standard EU 4
Clutch
Clutch design Multi-disk oil-bath clutch, slipper clutch
11
173
z Technical data
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
