Page #179 background imageLoading...
Page #179 background image
Brakes
Front wheel
Type of front brake Hydraulically operated twin disk brake with 4-pis-
ton radial calipers and floating brake disks
Front brake pad material Sintered metal
Rear wheel
Type of rear brake Hydraulically operated disk brake with 2-piston
floating caliper and fixed brake disk
Rear brake pad material Sintered metal
Wheels and tyres
Recommended tire combinations An overview of the current tire approvals is avail-
able from your authorized BMW Motorrad retailer
or on the Internet at bmw-motorrad.com.
Speed category of front/rear tires W, minimum requirement: 168 mph (270 km/h)
11
177
z
Technical data
ProCarManuals.com

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the BMW R 1200RS 2016 and is the answer not in the manual?

BMW R 1200RS 2016 Specifications

General IconGeneral
Displacement1170 cc
Bore x Stroke101 mm x 73 mm
Max Torque125 Nm at 6, 500 rpm
Compression Ratio12.5:1
Fuel SystemElectronic intake pipe injection
Final DriveShaft drive
ABSBMW Motorrad ABS
Top SpeedOver 200 km/h
Traction ControlStandard
Tires Front120/70 ZR17
Tires Rear180/55 ZR17
Max Power125 hp (92 kW) @ 7750 rpm
Transmission6-speed
FrameTwo-section frame, front- and bolted-on rear frame
Rear SuspensionCast aluminium single-sided swing arm with BMW Motorrad Paralever
Front BrakesDual disc brake, diameter 320 mm, 4-piston calipers
Rear BrakesSingle disc brake, diameter 276 mm, 2-piston caliper
Seat Height820 mm
Fuel Capacity18 liters
Dry Weight231 kg
Wheelbase1530 mm
Engine TypeAir/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
