BMW R 1200RS 2016 User Manual

remains off or continues to
flash.
ABS is switched on.
As an alternative, the ignition
can also be switched off and
then on again.
ABS error
If the ABS indicator light lights
up after switching the ignition
off and on and then contin-
uing to ride above the mini-
mum speed, an ABS fault has
occurred. (Minimum speed
3 mph (5 km/h))
Automatic Stability
Control (ASC)
Deactivating ASC/DTC
NOTICE
You can find more detailed in-
formation regarding ASC and
DTC in the "Technology in de-
tail" chapter.
Switch on ignition ( 46).
Press and hold button 1 until
the ASC/DTC indicator and
warning light changes its
display behavior.
NOTICE
The ASC/DTC function can also
be deactivated while riding.
lights up.
Release button 1 within two
seconds.
continues to light up.
ASC/DTC is now deactivated.
Activating ASC/DTC
Press and hold button 1 until
the ASC/DTC indicator and
4
66
z Operation
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
