BMW R 1200RS 2016 User Manual

Multifunction display
(Full view)
1 Clock ( 59)
2 Tachometer
3 Trip distance
Onboard computer dis-
plays ( 56)
4 ESA setting ( 67)
5 Red speed range ( 43)
6 Fuel level
7 Outside temperature warn-
ing ( 41)
8 Riding mode ( 69)
9 Tire Pressure Control
Onboard computer dis-
plays ( 56)
10 Heated grip settings
( 74)
11 Gear indicator, shows "N"
in neutral (idling)
3
21
z Displays
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
