BMW R 1200RS 2016 User Manual

Limit range for outside
temperature
Approx. 37 °F (Approx. 3 °C)
In addition, the ice crystal
symbol 2 is displayed.
WARNING
Risk of black ice, even above
37 °F (3 °C)
Accident hazard
At a low outside temperature,
icy conditions must expected
on bridges and in shady road
areas.
Tire inflation pressure
with Tire Pressure Control
(TPC/RDC)
OE
The tire pressures are
shown adjusted for tem-
perature on the multifunction
display and are always relative
to the following tire air temper-
ature:
68 °F (20 °C)
The figure on the left side 2 in-
dicates the front tire's inflation
pressure, while the figure on the
right 3 shows the inflation pres-
sure in the rear tire. Immediately
after switching on the ignition,
"-- --" is indicated.
TPC/RDC sensor is not
active
min 19 mph (min 30 km/h)
(The TPC/RDC sensor does
not transmit a signal to the
motorcycle until this minimum
speed has been exceeded.)
If the 1 symbol appears at
the same time, the display
is a warning. The critical tire-
inflation pressure flashes.
If the level concerned is
borderline in terms of the
permissible tolerance, the gen-
eral warning light also shows yel-
low. If the monitored tire inflation
pressure is outside the permis-
sible tolerance range the general
warning light will flash in red.
3
42
z Displays
ProCarManuals.com

BMW R 1200RS 2016 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
ABS	BMW Motorrad ABS
Top Speed	Over 200 km/h
Traction Control	Standard
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Max Power	125 hp (92 kW) @ 7750 rpm
Transmission	6-speed
Frame	Two-section frame, front- and bolted-on rear frame
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Dual disc brake, diameter 320 mm, 4-piston calipers
Rear Brakes	Single disc brake, diameter 276 mm, 2-piston caliper
Seat Height	820 mm
Fuel Capacity	18 liters
Dry Weight	231 kg
Wheelbase	1530 mm
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
